SGPD-7306-1050

Data and Features

SGPD 7306-1050

Lock Point

2

Standard Doors (Single or Double Leaf)

YES

Door Width

650mm < ≤ 1320mm

YES

Door Height

≤ 2100mm

YES

≤ 3000mm

Option

Max Door Weight (kg)

200

Non-Handed Design

YES

Dogging Device

Option

Security Anti-Thrust Latch

NO

Fire and Smoke Check Doors

YES

Trim Optional

SGPD-7010

Option

Door Leaf Thickness Up to 50mm

YES

Extended Handle Spindle and Bolts for Door Leaf Thickness 50 - 105mm

Option

Approved to EN1125

YES

Fire Rate EN1634

YES

CE Mark for Building Products

YES

Material

Stainless Steel 304

YES

Steel, Painting

Option
